Mapping primer#

Scoring procedure#

The steps presented here is the hierarchical order. It does not necessarily represent the actual order in which things are computed.

1. Runtime overrides (type: UserOverrideFunction); set score = ∞ for the desired match , and score = -∞ for others [1].

2. Static overrides (type: dict or InheritedKeysDict); set score = ∞ for the desired match, and score = -∞ for others [1].

3. Filtering (type: FilterFunction); set score = -∞ for undesirable matches only.

4. If there are any Heuristics (type: HeuristicScore), apply..

   1. Short-circuiting (type: FilterFunction); reinterpret a FilterFunction such that the returned candidates (if any) are treated as overrides [1].

   2. Aliasing (type: AliasFunction); try to improve ScoreFunction accuracy by applying heuristics to the (value, candidates)-argument pairs.

   3. Finally, select the best score at each stage (from no to all heuristics) for each pair.

5. Regular score (type: ScoreFunction); higher is better.

The final output of the scoring procedure is a score matrix (a pandas DataFrame), where columns are candidates and values make up the index.

The full score matrix has over 100 values (rows). The table above contains a subset of 20. The 'rental_date' value can be seen having only negative-infinity matching scores. This is intentional; the database has no suitable table for translating dates. Mapping would’ve most likely failed regardless, but explicitly stating that 'rental_date' should not be translated (by using a filter) is more efficient. More importantly, it is also clearer.

Matching procedure#

Given precomputed match scores (see the section above), make as many matches as possible given a Cardinality restriction. These may be summarized as:

• OneToOne = ‘1:1’. Each value and candidate may be used at most once.

• OneToMany = ‘1:N’: Values have exclusive ownership of matched candidate(s).

• ManyToOne = ‘N:1’: Ensure that as many values as possible are unambiguously mapped (i.e. to a single candidate). This is the default option for new Mapper instances.

• ManyToMany = ‘M:N’: All matches above the score limit are kept.

In theory, OneToMany and ManyToOne are equally restrictive. During mapping however, the goal is usually to find matches for the values, not candidates. With that in mind, the ordering above may considered strictly decreasing in preciseness.

Troubleshooting#

Unmapped values are allowed by default. If mapping failure is not an acceptable outcome for your application, initialize the Mapper with unmapped_values_action='raise' to ensure that an error is raised for unmapped values.

rics.mapping.Mapper.accept: Accepted: 'b' -> 'b'; score=1.000 >= 0.1.
rics.mapping.Mapper.accept.details: This match supersedes 4 other matches:
  'b' -> 'ab'; score=0.500 (superseded on value='b').
  'b' -> 'a'; score=0.000 < 0.1 (below threshold).
  'b' -> 'fixed'; score=0.000 < 0.1 (below threshold).
  'a' -> 'b'; score=-inf (superseded by short-circuit or override).
rics.mapping.Mapper: Match selection with cardinality='OneToOne' completed in 0.00369605 sec.

 rics.mapping.Mapper.unmapped.details: Could not map value='is_nice':
   'is_nice' -> 'name'; score=0.125 < 1.0 (below threshold).
   'is_nice' -> 'gender'; score=0.083 < 1.0 (below threshold).
   'is_nice' -> 'id'; score=0.000 < 1.0 (below threshold).
 rics.mapping.Mapper.unmapped: Could not map {'is_nice'} in context='humans' to any of candidates={'name', 'gender', 'id'}.

from rics.mapping import Mapper, support
with support.enable_verbose_debug_messages():
    Mapper(<config>).apply(<values>, <candidates>)

rics.mapping.Mapper.accept: Accepted: 'a' -> 'ab'; score=inf (short-circuit or override).
rics.mapping.filter_functions.require_regex_match: Refuse matching for name='a': Matches pattern=re.compile('.*a.*', re.IGNORECASE).
rics.mapping.HeuristicScore: Heuristics scores for value='staff_id': ['store': 0.00 -> 0.50 (+0.50), 'payment': 0.07 -> 0.07 (+0.00), 'inventory': 0.00 -> 0.07 (+0.07), 'language': 0.00 -> 0.08 (+0.08), 'category': 0.00 -> 0.04 (+0.04), 'film': 0.05 -> 0.10 (+0.05), 'address': 0.00 -> 0.08 (+0.08), 'rental': 0.00 -> 0.08 (+0.08), 'customer_list': 0.00 -> 0.02 (+0.02), 'staff': 0.00 -> 1.00 (+1.00), 'staff_list': 0.00 -> 0.03 (+0.03), 'city': 0.00 -> 0.10 (+0.10), 'country': 0.00 -> 0.06 (+0.06), 'customer': 0.00 -> 0.04 (+0.04), 'actor': 0.00 -> 0.17 (+0.17)]
rics.mapping.filter_functions.require_regex_match: Refuse matching for name='return_date': Does not match pattern=re.compile('.*_id$', re.IGNORECASE).
