Mapping primer#

Overrides and filtering#

Overrides and filtering adhere to a strict hierarchy (the one presented below). Overrides take precedence over filters, and runtime overrides takes precedence over static overrides.

1. Runtime overrides (type: UserOverrideFunction); set score=∞ for the chosen candidate, and score=-∞ for others.

2. Static overrides (type: dict or InheritedKeysDict); set score=∞ for the chosen candidate, and score=-∞ for others.

3. Filtering (type: FilterFunction); set score=-∞ for undesirable matches only.

Score computations#

4. Compute value-candidate match scores (type: ScoreFunction). Higher is better.

5. If there are any Heuristics (type: HeuristicScore), apply..

   1. Short-circuiting (type: FilterFunction); reinterpret a FilterFunction such that the returned candidates (if any) are treated as overrides.

   2. Aliasing (type: AliasFunction); try to improve ScoreFunction accuracy by applying heuristics to the (value, candidates)-argument pairs.

   3. Finally, select the best score at each stage (from no to all heuristics) for each pair.

The final output is a score matrix (type: pandas.DataFrame), where columns are candidates and values make up the index.

The 'rental_date'-value can be seen having only negative-infinity matching scores due to filtering. Mapping would’ve likely failed for this value regardless, but using explicit filters clearly indicates that translation is not wanted.

Conflict resolution#

When a single match out of multiple viable options must be chosen due to cardinality restrictions, priority is determined by the iteration order of values and candidates. The first value will prefer the first candidate, and so on. This logic does not consider future matches.

>>> mapper = Mapper(cardinality='1:1', score_function=lambda value, *_: [1, 0] if value == 'v1' else [1, 1])
>>> mapper.compute_scores(['v0', 'v1'], ['c0', 'c1'])
candidates   c0   c1
values
v0          1.0  1.0
v1          0.0  1.0
>>> mapper.apply(['v0', 'v1'], ['c0', 'c1']).flatten()
{'val0': 'cand0'}

Notice that val1 was left without a match, even though it could’ve been assigned to cand0 if the equally viable matching val0 → cand1 had been chosen first.

Mapper .details-messages#

The 'rics.mapping.Mapper.accept.details' and 'rics.mapping.Mapper.unmapped.details' loggers emit per-combination mapping scores when matches are made (accept.details), or when values are left without a match (unmapped.details). Records from these loggers are always emitted on the debug-level.

rics.mapping.Mapper.accept: Accepted: 'v0' -> 'c0'; score=1.000 >= 1.0.
rics.mapping.Mapper.accept.details: This match supersedes 2 other matches:
    'v0' -> 'c1'; score=1.000 (superseded on value='v0').
    'v1' -> 'c0'; score=1.000 (superseded on candidate='c0').

 rics.mapping.Mapper.unmapped.details: Could not map value='v1':
     'v1' -> 'c0'; score=1.000 (superseded on candidate='c0': 'v0' -> 'c0'; score=1.000).
     'v1' -> 'c1'; score=0.000 < 1.0 (below threshold).

Unlike the unmapped.details-logger, the level of the records emitted by its parent (the unmapped-logger) is determined by the Mapper.unmapped_values_action-attribute ( 'ignore' emits on the debug-level).

Verbose messages#

If .details-logging is not enough, the last resort (before opening a debugger) is to enable verbose logging. The recommended way of doing this is by using the enable_verbose_debug_messages()-method, which acts as a context manager.

from rics.mapping import Mapper, support
with support.enable_verbose_debug_messages():
    Mapper(<config>).apply(<values>, <candidates>)

Verbose mode enables debug-level log messages from individual functions involved in the decision making and mapping procedure, describing the internal operation of the Mapper in great detail.

rics.mapping.Mapper.accept: Accepted: 'a' -> 'ab'; score=inf (short-circuit or override).
rics.mapping.filter_functions.require_regex_match: Refuse matching for name='a': Matches pattern=re.compile('.*a.*', re.IGNORECASE).
rics.mapping.HeuristicScore: Heuristics scores for value='staff_id': ['store': 0.00 -> 0.50 (+0.50), 'payment': 0.07 -> 0.07 (+0.00), 'inventory': 0.00 -> 0.07 (+0.07), 'language': 0.00 -> 0.08 (+0.08), 'category': 0.00 -> 0.04 (+0.04), 'film': 0.05 -> 0.10 (+0.05), 'address': 0.00 -> 0.08 (+0.08), 'rental': 0.00 -> 0.08 (+0.08), 'customer_list': 0.00 -> 0.02 (+0.02), 'staff': 0.00 -> 1.00 (+1.00), 'staff_list': 0.00 -> 0.03 (+0.03), 'city': 0.00 -> 0.10 (+0.10), 'country': 0.00 -> 0.06 (+0.06), 'customer': 0.00 -> 0.04 (+0.04), 'actor': 0.00 -> 0.17 (+0.17)]
rics.mapping.filter_functions.require_regex_match: Refuse matching for name='return_date': Does not match pattern=re.compile('.*_id$', re.IGNORECASE).

To permanently enable verbose logging, initialize with enable_verbose_logging=True.
